Draw an Ascending Volute


Article Image

Not too long ago a fellow requested about how to attract a volute wherein the
middle is greater that the skin. This might be for the columns
on an ornamental hearth encompass. Right here’s a technique that works
fairly effectively. I used three extensions: Curve
Maker
 andCLF
Shape Bender
 each from the Extension Warehouse and
TIG-Weld
from the Sketchucation Plugin Retailer. If you happen to don’t have already got
these, you need to let SketchUp set up them routinely by way of
the Extension Warehouse and Sketchucation Plugin Retailer instruments.

Towards the tip of the video I spent a little bit of time cleansing up
unneeded edges and faces in order that I may make a strong part
of the volute. Whereas it isn’t completely neccesary to have
strong parts for woodworking tasks, they do symbolize
very clear modeling. Parts are a lot simpler to work with
when they’re solids and I extremely advocate you shoot for
making your entire parts present as strong.

Dave
