Converting Geometry to Components


Article Image

The opposite day I obtained an e-mail from a gentleman who asking
for some SketchUp assist. It appears he’d gotten so concerned in
drawing his mannequin, he’d forgotten to make elements as he
progressed with the work. Because of the sticky nature of geometry
in SketchUp, he now had an enormous lump of geometry for the face
body and the highest of his cupboard. This was going to create a
variety of issues for him later and he wished to know if he
may keep away from having to attract all these elements from scratch. There
are a number of methods to do it. The next video exhibits the strategy
I confirmed him. I feel that is the best and least more likely to
trigger errors.

As an alternative of utilizing his mannequin, I’ve setup the door on a mannequin I
created just lately. I did initially draw the door because the 5
separate elements together with the joinery. For this video I exploded
the elements and deleted all the inner edges and faces. In
this mannequin, I already had the door as a element however this
methodology would work simply as effectively with free geometry.

There are instances through which you may deliberately draw a mannequin
with out making elements of the elements as you go after which
later, you want to have the separate elements. You need to use
this course of to shortly make the conversion. In case you have mode
complicated shapes comparable to profiled edges, chances are you’ll want to repeat
them in addition to the faces I present right here.


Within the subsequent weblog submit I’ll undergo including the joinery to the
door elements now that they’re elements.

Dave
